- Video And Audio
- IP Video Input16-ch,Up to 8 MP resolution
- Video Resolution8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF
- Incoming/Outgoing Bandwidth80 Mbps,160 Mbps
- HDMI Output1-ch, 4K (3840 × 2160)/30Hz, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
- VGA Output1-ch, 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
- Audio Output1-ch, RCA (Linear, 1 KΩ)
- Two-Way Audio Input1-ch, RCA (2.0 Vp-p, 1 k Ω)
- Decoding
- Decoding FormatH.265/H.265+/H.264/H.264+/MPEG4
- Recording Resolution8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF
- Synchronous Playback16-ch
- Capability1-ch @ 8 MP / 4-ch @ 1080p
- Network
- Network ProtocolsTCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
- Network Interface1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
- POE Interface
- Interface16, RJ-45 10/100 Mbps self-adaptive Ethernet interface
- Power≤ 150W
- Supported StandardIEEE 802.3 af/at
- Hard Disk
- SATA2 SATA interfaces
- CapacityUp to 6TB capacity for each disk
- External Interface
- USB Interface2 × USB 2.0
- General
- Power Supply100 to 240 VAC,≤ 280W
- Consumption (Without HDD)≤ 15W
- Working Temperature-10 to +55º C (+14 to +131º F)
- Working Humidity10 to 90 %
- Dimensions (W × D × H)385 × 315 × 52 mm (15.2″× 12.4″ × 2.0″)
- Weight (Without Hard Disk)≤ 2.6 kg (5.7 lb)
- Chassis1U chassis
