- Camera
- Image Sensor5 MP CMOS
- Signal SystemPAL/NTSC
- Frame RateTVI: 5MP@20fps, 4MP@30fps, 4MP@25fps, 1080p@30fps, 1080p@25fps CVI: 4MP@30fps, 4MP@25fps AHD: 5MP@20fps, 4MP@30fps, 4MP@25fps CVBS: PAL/NTSC
- Resolution2560 (H) × 1944 (V)
- Min. Illumination0.0005 Lux @ (F1.0, AGC ON), 0 Lux with White Light
- Shutter TimePAL: 1/25 s to 1/50, 000 s NTSC: 1/30 s to 1/50, 000 s
- Lens3.6 mm, 6 mm fixed lens
- Horizontal Field Of View80.1° (3.6 mm), 49.3° (6 mm)
- Lens MountM16
- Strobe Light AlarmYes
- Day & NightColor
- WDR (Wide Dynamic Range)≥130 dB
- Angle AdjustmentPan: 0 to 360°, Tilt: 0 to 75°, Rotation: 0 to 360°
- Menu
- White LightAuto/Off
- Image ModeSTD/HIGH-SAT
- AGCYes
- Day/Night ModeColor
- White BalanceAuto/Manual
- HLCYes
- BLC (Backlight Compensation)Yes
- LanguageEnglish
- FunctionsBrightness, Sharpness, Mirror, Smart Light
- Interface
- Video OutputSwitchable TVI/AHD/CVI/CVBS
- General
- Operating Condition‘-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)
- Power Supply12 VDC ± 25% *You are recommended to use one power adapter to supply the power for one camera.
- Power ConsumptionMax. 3.5 W
- Protection LevelIP67
- MaterialFront Cover: Metal Main Body: Plastic
- CommunicationHIKVISION-C
- White Light RangeUp to 20m
- DimensionsΦ 109.82 mm × 85.56 mm (4.32″ × 3.37″)
- WeightApprox. 350 g ( 0.77 lb.)
