Camera
Image Sensor 1/2.8″ Progressive Scan CMOS
Min. Illumination Color: 0.01 Lux @ (F1.2, AGC ON), 0.028Lux @(F2.0, AGC ON);
B/W: 0.001 Lux @(F1.2, AGC ON), 0.0028 Lux @(F2.0, AGC ON)
Shutter Speed 1/3 s to 1/100,000 s
Slow Shutter Yes
Auto-Iris No
Day & Night IR Cut Filter
Digital Noise Reduction 3D DNR
WDR 120 dB
Lens
Focal Length 4/6 mm
Aperture F2.0
Focus Fixed
FOV
4 mm: horizontal FOV: 86°, vertical FOV: 47°, diagonal FOV: 103°
6 mm: horizontal FOV: 55°, vertical FOV: 31°, diagonal FOV: 62°
Lens Mount M12
IR
IR Range 40 m
Wavelength 850nm
Compression Standard
Video Compression
Main stream: H.265/H.264
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264
H.264 Type Baseline Profile/Main Profile/High Profile
H.264+ Main stream supports
H.265 Type Main Profile
H.265+ Main stream supports
Video Bit Rate 32 Kbps to 8 Mbps
Audio Compression (-S) G.711/G.722.1/G.726/MP2L2/PCM
Audio Bit Rate (-S) 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)
Smart Feature-set
Behavior Analysis Line crossing detection, intrusion detection
Exception Detection Scene change detection, audio exception detection
Face Detection Yes
Region of Interest 1 fixed region for main stream
Max. Resolution 1920 × 1080
Main Stream 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720)
60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)
Sub-Stream
50Hz: 25fps (704 × 576, 640 × 480, 352 × 288, 320 × 240)
60Hz: 30fps (704 × 480, 640 × 480, 352 × 240, 320 × 240)
Third Stream 50Hz: 1fps (352 x 240, 320 x 240)
60Hz: 1fps (352 x 240, 320 x 240)
Image Enhancement BLC/3D DNR/HLC
Image Settings
Rotate mode, saturation, brightness, contrast, sharpness adjustable by client software or web
browser
Day/Night Switch Day/Night/Auto/Schedule/Triggered by alarm in (-S)
Network
Network Storage Support Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
Alarm Trigger Motion detection, video tampering, network disconnected, IP address conflict, illegal login, HDD
full, HDD error
Protocols TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP™, SMTP,
SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
General Function Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
Firmware Version V5.5.3
API ONVIF (PROFILE S, PROFILE G), ISAPI
Simultaneous Live View Up to 6 channels
User/Host
Up to 32 users
3 levels: Administrator, Operator and User
Client iVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500
Web Browser IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+
Interface
Audio (-S) 1 input (line in), 1 output (line out)
Communication Interface 1 RJ45 10M/100M self-adaptive Ethernet port
Alarm (-S) 1 input, 1 output
On-board Storage Built-in micro SD/SDHC/SDXC slot, up to 128 GB
Reset Button Yes
Audio (-S)
Environment Noise Filtering Yes
Audio Sampling Rate 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
General
Operating Conditions -30 °C to +60 °C (-22 °F to +140 °F), humidity 95% or less (non-condensing)
Power Supply 12 VDC ± 25%
PoE (802.3af, class 3)
Power Consumption and
Current
PoE: (802.3af, 36 V to 57 V), 0.2 A to 0.1 A, max: 6.5 W
12 VDC, 0.4 A, max. 5.0 W
Protection Level IP67
Material Front cover: metal, camera body: plastic, bracket: metal
Dimensions Camera: 93.9 × 93.5 × 194.1 mm (3.7″ × 3.7″ × 7.6″)
With package: 300 × 205 × 135 mm (11.8″ × 8.1″ × 5.3″)
Weight Camera: approx. 680 g (1.5 lb.)
With package: approx. 1000 g (2.2 lb.)
